Standard Roll End Bearings
| Part No. | Bore/Shaft Size | Tubing Gauge | OD | Material Code | Type | Length | Material | Quantity | |
|---|---|---|---|---|---|---|---|---|---|
| STU80T11 | Shaft Size = | 11 | 4.76 | U | Standard Roll End Bearings | 1-3/4" | White UHMW | ||
| STU64P80 | Shaft Size = | Sch. 80 | 3.826 | U | Standard Roll End Bearings | 1-3/4" | White UHMW | ||
| STU64P40 | Shaft Size = | Sch. 40 | 4.026 | U | Standard Roll End Bearings | 1-3/4" | White UHMW | ||
| STU64EMT | Shaft Size = | 4" EMT | 4.334 | U | Standard Roll End Bearings | 1-3/4" | White UHMW | ||
| STU72T11 | Shaft Size = | 11 | 4.26 | U | Standard Roll End Bearings | 1-3/4" | White UHMW | ||
| STU56P80 | Shaft Size = | Sch. 80 | 3.364 | U | Standard Roll End Bearings | 1-3/4" | White UHMW | ||
| STU56P40 | Shaft Size = | Sch. 40 | 3.548 | U | Standard Roll End Bearings | 1-3/4" | White UHMW | ||
| STU64T11 | Shaft Size = | 11 | 3.76 | U | Standard Roll End Bearings | 1-3/4" | White UHMW | ||
| STU64T13 | Shaft Size = | 13 | 3.81 | U | Standard Roll End Bearings | 1-3/4" | White UHMW | ||
| STU64T14 | Shaft Size = | 14 | 3.834 | U | Standard Roll End Bearings | 1-3/4" | White UHMW | ||
| STU64T16 | Shaft Size = | 16 | 3.87 | U | Standard Roll End Bearings | 1-3/4" | White UHMW | ||
| STU60T11 | Shaft Size = | 11 | 3.51 | U | Standard Roll End Bearings | 1-3/4" | White UHMW | ||
| STU60T16 | Shaft Size = | 16 | 3.62 | U | Standard Roll End Bearings | 1-3/4" | White UHMW | ||
| STU48P80 | Shaft Size = | Sch. 80 | 2.9 | U | Standard Roll End Bearings | 1-3/4" | White UHMW | ||
| STU48P40 | Shaft Size = | Sch. 40 | 3.068 | U | Standard Roll End Bearings | 1-3/4" | White UHMW | ||
| STU48EMT | Shaft Size = | 3" EMT | 3.356 | U | Standard Roll End Bearings | 1-3/4" | White UHMW | ||
| STU56T11 | Shaft Size = | 11 | 3.26 | U | Standard Roll End Bearings | 1-3/4" | White UHMW | ||
| STU56T13 | Shaft Size = | 13 | 3.31 | U | Standard Roll End Bearings | 1-3/4" | White UHMW | ||
| STU56T16 | Shaft Size = | 16 | 3.37 | U | Standard Roll End Bearings | 1-3/4" | White UHMW | ||
| STU52T13 | Shaft Size = | 13 | 3.06 | U | Standard Roll End Bearings | 1-3/4" | White UHMW | ||
| STU52T16 | Shaft Size = | 16 | 3.12 | U | Standard Roll End Bearings | 1-3/4" | White UHMW | ||
| STU48T11 | Shaft Size = | 11 | 2.76 | U | Standard Roll End Bearings | 1-3/4" | White UHMW | ||
| STU48T12 | Shaft Size = | 12 | 2.782 | U | Standard Roll End Bearings | 1-3/4" | White UHMW | ||
| STU48T13 | Shaft Size = | 13 | 2.81 | U | Standard Roll End Bearings | 1-3/4" | White UHMW | ||
| STU48T14 | Shaft Size = | 14 | 2.834 | U | Standard Roll End Bearings | 1-3/4" | White UHMW | ||
| STU48T16 | Shaft Size = | 16 | 2.87 | U | Standard Roll End Bearings | 1-3/4" | White UHMW | ||
| STU48T18 | Shaft Size = | 18 | 2.902 | U | Standard Roll End Bearings | 1-3/4" | White UHMW | ||
| STU40P80 | Shaft Size = | Sch. 80 | 2.323 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU40P40 | Shaft Size = | Sch. 40 | 2.469 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU46T11 | Shaft Size = | 11 | 2.635 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU44T11 | Shaft Size = | 11 | 2.51 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU44T13 | Shaft Size = | 13 | 2.56 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU44T16 | Shaft Size = | 16 | 2.62 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU44T18 | Shaft Size = | 18 | 2.652 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU40T10 | Shaft Size = | 10 | 2.232 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU40T11 | Shaft Size = | 11 | 2.26 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU40T12 | Shaft Size = | 12 | 2.282 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU40T13 | Shaft Size = | 13 | 2.31 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU40T14 | Shaft Size = | 14 | 2.334 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU40T16 | Shaft Size = | 16 | 2.37 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU40T18 | Shaft Size = | 18 | 2.402 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU32P80 | Shaft Size = | Sch. 80 | 1.939 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU32P40 | Shaft Size = | Sch. 40 | 2.067 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU32P10 | Shaft Size = | 10 | 2.157 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU38T11 | Shaft Size = | 11 | 2.135 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU38T13 | Shaft Size = | 13 | 2.185 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU38T14 | Shaft Size = | 14 | 2.209 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU38T16 | Shaft Size = | 16 | 2.245 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU36T10 | Shaft Size = | 10 | 1.982 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU36T11 | Shaft Size = | 11 | 2.01 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU36T13 | Shaft Size = | 13 | 2.06 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU36T14 | Shaft Size = | 14 | 2.084 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU36T16 | Shaft Size = | 16 | 2.12 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU36T18 | Shaft Size = | 18 | 2.152 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU32EMT | Shaft Size = | 2" EMT | 2.067 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU34T16 | Shaft Size = | 16 | 1.995 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU32T10 | Shaft Size = | 10 | 1.732 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU32T11 | Shaft Size = | 11 | 1.76 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU32T12 | Shaft Size = | 12 | 1.782 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU32T13 | Shaft Size = | 13 | 1.81 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU32T14 | Shaft Size = | 14 | 1.834 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU32T16 | Shaft Size = | 16 | 1.87 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU32T18 | Shaft Size = | 18 | 1.902 | U | Standard Roll End Bearings | 1-5/8" | White UHMW | ||
| STU24P80 | Shaft Size = | Sch. 80 | 1.5 | U | Standard Roll End Bearings | 1-1/2" | White UHMW | ||
| STU24P40 | Shaft Size = | Sch. 40 | 1.61 | U | Standard Roll End Bearings | 1-1/2" | White UHMW | ||
| STU31T12 | Shaft Size = | 12 | 1.682 | U | Standard Roll End Bearings | 1-1/2" | White UHMW | ||
| STU31T16 | Shaft Size = | 16 | 1.77 | U | Standard Roll End Bearings | 1-1/2" | White UHMW | ||
| STU30T13 | Shaft Size = | 13 | 1.685 | U | Standard Roll End Bearings | 1-1/2" | White UHMW | ||
| STU30T16 | Shaft Size = | 16 | 1.745 | U | Standard Roll End Bearings | 1-1/2" | White UHMW | ||
| STU30T18 | Shaft Size = | 18 | 1.777 | U | Standard Roll End Bearings | 1-1/2" | White UHMW | ||
| STU28T11 | Shaft Size = | 11 | 1.51 | U | Standard Roll End Bearings | 1-1/2" | White UHMW | ||
| STU28T13 | Shaft Size = | 13 | 1.56 | U | Standard Roll End Bearings | 1-1/2" | White UHMW | ||
| STU28T14 | Shaft Size = | 14 | 1.584 | U | Standard Roll End Bearings | 1-1/2" | White UHMW | ||
| STU28T16 | Shaft Size = | 16 | 1.62 | U | Standard Roll End Bearings | 1-1/2" | White UHMW | ||
| STU28T20 | Shaft Size = | 20 | 1.68 | U | Standard Roll End Bearings | 1-1/2" | White UHMW | ||
| STU24EMT | Shaft Size = | 1-1/2" EMT | 1.61 | U | Standard Roll End Bearings | 1-1/2" | White UHMW | ||
| STU20P80 | Shaft Size = | Sch. 80 | 1.27 | U | Standard Roll End Bearings | 1-1/2" | White UHMW | ||
| STU20P40 | Shaft Size = | Sch. 40 | 1.38 | U | Standard Roll End Bearings | 1-1/2" | White UHMW | ||
| STU26T11 | Shaft Size = | 11 | 1.385 | U | Standard Roll End Bearings | 1-1/2" | White UHMW | ||
| STU26T13 | Shaft Size = | 13 | 1.435 | U | Standard Roll End Bearings | 1-1/2" | White UHMW | ||
| STU26T16 | Shaft Size = | 16 | 1.495 | U | Standard Roll End Bearings | 1-1/2" | White UHMW | ||
| STU20EMT | Shaft Size = | 1-1/4" | 1.38 | U | Standard Roll End Bearings | 1-1/2" | White UHMW | ||
| STU24T11 | Shaft Size = | 11 | 1.26 | U | Standard Roll End Bearings | 1-1/2" | White UHMW | ||
| STU24T14 | Shaft Size = | 14 | 1.334 | U | Standard Roll End Bearings | 1-1/2" | White UHMW | ||
| STU24T16 | Shaft Size = | 16 | 1.37 | U | Standard Roll End Bearings | 1-1/2" | White UHMW | ||
| STU24T18 | Shaft Size = | 18 | 1.402 | U | Standard Roll End Bearings | 1-1/2" | White UHMW | ||
| STU22T16 | Shaft Size = | 16 | 1.245 | U | Standard Roll End Bearings | 1-1/4" | White UHMW | ||
| STU22T17 | Shaft Size = | 17 | 1.259 | U | Standard Roll End Bearings | 1-1/4" | White UHMW | ||
| STU22T18 | Shaft Size = | 18 | 1.244 | U | Standard Roll End Bearings | 1-1/4" | White UHMW | ||
| STU16P80 | Shaft Size = | Sch. 80 | 0.957 | U | Standard Roll End Bearings | 1-1/4" | White UHMW | ||
| STU16P40 | Shaft Size = | Sch. 40 | 1.049 | U | Standard Roll End Bearings | 1-1/4" | White UHMW |
